Does anyone one have any good pics of the hydraulic rams on either side of the flail mechanism on a Sherman Crab? These rams would be used to raise or lower the flail unit but I can't see where the hoses would attach? Or were any attached and it used a different method?

Gary

Do you know these pics ?

http://militarymodels.co.nz/2012/04/18/photo-walkaround-sherman-m4a4-crab/

Here you can see one of the hoses still in place :

http://preservedtanks.com/Handler.ashx?PhotoID=6189&Size=L&Dir=~/Albums&File=P1030971_ShermanCrab_Bov_AA_c.jpg

H.P.

Thanks H.P. Very useful pics there. Any idea where the hoses go through the hull?

Gary

On the left side, the hose appears to be connected to the "box" above...



Full size

H.P.
